TurtleBot 4 ships fully assembled with ROS 2 pre-installed and configured along with detailed user documentation, an Ignition Gazebo simulation model, demo code and a suite of tutorials, allowing you to get started quickly with developing robotics applications.
TurtleBot 4 comes with an array of integrated sensors ideal for many robotics applications. Onboard sensors include the OAK-D spatial AI stereo camera, 2D Lidar, IMU, optical floor tracking sensor, wheel encoders, infrared, cliff, bump, slip detection and more. All onboard sensors are available as ROS topics via the network-connected ROS 2 API.
TurtleBot 4 is built on the iRobot® Create 3 educational robot – a sturdy mobile base which provides an array of intelligent sensors for accurate localization and positioning, a 9kg payload capacity out-of-the-box and up to 15 kg with a custom configuration, and a top speed of .306 m/s. The Create 3 has a standalone ROS interface and unlike previous TurtleBots, it includes integrated batteries and a charging dock.
Once you’ve mastered the basics, easily expand the capabilities of TurtleBot 4 by adding your own sensors and custom payloads. Accessible USB ports, power breakouts and a top mounting plate make it easy to integrate third-party hardware and components. With ROS 2 and its support for micro-ROS, expansion and integration of embedded microcontrollers is made easier than ever.
TurtleBot is an open source platform and you can get the design and software here. You’re encouraged to try it out, extend it, or build your own. For every TurtleBot 4 shipped, a portion of the proceeds goes to the Open Robotics for the continued support of the development, distribution, and adoption of open source software in robotics research and education.
TurtleBot 4 comes in two models: TurtleBot 4 Standard and TurtleBot 4 Lite. While both models are built on the powerful iRobot® Create 3 mobile base, TurtleBot 4 Standard offers an OLED screen, an upgraded Spatial AI stereo camera, and a mounting plate with accessible user power and USB ports for easily integrating payloads and accessories.
TurtleBot 4 Standard |  |
TurtleBot 4 Lite |
| 341 x 339 x 351 mm | Dimensions | 341 x 339 x 192 mm |
| 3.9 kg | Weight | 3.3 kg |
| 0.31 m/s | Max. Speed | 0.31 m/s |
9 kg - Default 15 kg - Custom Configuration | Max. Payload | 9 kg - Default 15 kg - Custom Configuration |
| 2.5 - 4.0 hrs (load dependent) | Operating Time | 2.5 - 4.0 hrs (load dependent) |
| OAK-D-PRO | Camera | OAK-D-LITE |
| RPLIDAR-A1 | LiDAR | RPLIDAR-A1 |
| Yes | Accessible Power & USB Ports | No |
| Yes | OLED Display | No |
| Yes | Mounting Plate | No |
| ROS 2 | Software | ROS 2 |
| Raspberry Pi 4B (4 GB) | Computer | Raspberry Pi 4B (4 GB) |
TurtleBot 4 ships fully assembled with ROS 2 pre-installed and configured along with detailed user documentation, an Ignition Gazebo simulation model, demo code and a suite of tutorials, allowing you to get started quickly with developing robotics applications.
TurtleBot 4 comes with an array of integrated sensors ideal for many robotics applications. Onboard sensors include the OAK-D spatial AI stereo camera, 2D Lidar, IMU, optical floor tracking sensor, wheel encoders, infrared, cliff, bump, slip detection and more. All onboard sensors are available as ROS topics via the network-connected ROS 2 API.
TurtleBot 4 is built on the iRobot® Create 3 educational robot – a sturdy mobile base which provides an array of intelligent sensors for accurate localization and positioning, a 9kg payload capacity out-of-the-box and up to 15 kg with a custom configuration, and a top speed of .306 m/s. The Create 3 has a standalone ROS interface and unlike previous TurtleBots, it includes integrated batteries and a charging dock.
Once you’ve mastered the basics, easily expand the capabilities of TurtleBot 4 by adding your own sensors and custom payloads. Accessible USB ports, power breakouts and a top mounting plate make it easy to integrate third-party hardware and components. With ROS 2 and its support for micro-ROS, expansion and integration of embedded microcontrollers is made easier than ever.
TurtleBot is an open source platform and you can get the design and software here. You’re encouraged to try it out, extend it, or build your own. For every TurtleBot 4 shipped, a portion of the proceeds goes to the Open Robotics for the continued support of the development, distribution, and adoption of open source software in robotics research and education.
TurtleBot 4 comes in two models: TurtleBot 4 Standard and TurtleBot 4 Lite. While both models are built on the powerful iRobot® Create 3 mobile base, TurtleBot 4 Standard offers an OLED screen, an upgraded Spatial AI stereo camera, and a mounting plate with accessible user power and USB ports for easily integrating payloads and accessories.
TurtleBot 4 Standard | |
TurtleBot 4 Lite |
| 341 x 339 x 351 mm | Dimensions | 341 x 339 x 192 mm |
| 3.9 kg | Weight | 3.3 kg |
| 0.31 m/s | Max. Speed | 0.31 m/s |
9 kg - Default 15 kg - Custom Configuration | Max. Payload | 9 kg - Default 15 kg - Custom Configuration |
| 2.5 - 4.0 hrs (load dependent) | Operating Time | 2.5 - 4.0 hrs (load dependent) |
| OAK-D-PRO | Camera | OAK-D-LITE |
| RPLIDAR-A1 | LiDAR | RPLIDAR-A1 |
| Yes | Accessible Power & USB Ports | No |
| Yes | OLED Display | No |
| Yes | Mounting Plate | No |
| ROS 2 | Software | ROS 2 |
| Raspberry Pi 4B (4 GB) | Computer | Raspberry Pi 4B (4 GB) |
